Web cloud server ZKT OEM Hybrid Biometric Attendance Device Face Fingerprint Palm Recognition Access Control System
Short Description:
FA1-PRO is powered by Computer Vision technology like 3-in-1 contactless palm recognition, which means the terminal can perform bio-authentication with a user’s palm vein, palm print, and the shape of palm at the same time once the sensor detects a hand presented. Palm vein and palm print patterns are reliable human identifiers as the details are extremely hard to be duplicated, thus, together with the powerful algorithm, users may enjoy the terminal’s enhanced anti-spoofing ability. Eliminating hygienic concerns, FA1-PRO, equipped with a novel hand tracking technique allowing angle tolerance as wide as + or – 60 in the roll axis, the huge capacity of 6000 palm templates, and a 1.4GHz quad-core CPU, extracts palm print and vein pattern for analysis at a distance for recognition from 0.2m to 0.5m in less than 0.35 seconds. Users no longer need to struggle to touch the sensor at a specific angle and align the center of the palm with the center of the input sensor for proper hand images to be acquired.
Web cloud server ZKT OEM Hybrid Biometric Attendance Device Face Fingerprint Palm Recognition Access Control System
Introduction:
FA1-PRO is powered by Computer Vision technology like 3-in-1 contactless palm recognition, which means the terminal can perform bio-authentication with a user’s palm vein, palm print, and the shape of palm at the same time once the sensor detects a hand presented.
Palm vein and palm print patterns are reliable human identifiers as the details are extremely hard to be duplicated, thus, together with the powerful algorithm, users may enjoy the terminal’s enhanced anti-spoofing ability.
Eliminating hygienic concerns, FA1-PRO, equipped with a novel hand tracking technique allowing angle tolerance as wide as + or – 60 in the roll axis, the huge capacity of 6000 palm templates, and a 1.4GHz quad-core CPU, extracts palm print and vein pattern for analysis at a distance for recognition from 0.2m to 0.5m in less than 0.35 seconds. Users no longer need to struggle to touch the sensor at a specific angle and align the center of the palm with the center of the input sensor for proper hand images to be acquired.
Features:
–Multi-Biometric verification mode: Palm/Face/Fingerprint and card (optional)
–6,000 palm templates,12,000 face templates, 20,000 fingerprint and 20,000 cards ,big capacity
–Time attendance application, also with built-in relay for access control function
–Able to detect whether the face is an actual face or a photo, enhancing the security level of verification
–Backup battery provides approximate 3 hours of continuous operation
–Communication via TCP/IP, RS232/485 and USB, WIFl or 4G is optional
–Support 1.4GHz Quad Core CPU, Rapid recognition speed
–Optional Wifi,3G or 4G
–Web-based Attendance Software UTime Master or BioTime8.0 or ZKCVAccess IVS (Granding UAccess Master)
Working Application:
Specifications:
|
Model |
FA1-PRO |
|
Cameras |
High Definition Infrared Cameras |
|
Display |
4.3-inch TFT Touch Screen |
|
Speaker |
Voice Prompt |
|
Capacity |
Face:12,000 Fingerprint: 20,000 Palm:6,000 Card:20,000 (optional) |
|
Algorithms |
Face V12.0 & Fingerprint V10.0 & Palm V12.0 |
|
CPU |
1.4GHz Quad Core CPU, Memory 1G RAM /1G Flash |
|
Verification |
Verification speed (1:1) <=0.5S Identification speed(1:N)<=1S |
|
Identification |
Fingerprint : FAR<=0.0001%;FRR<=0.01% Face: FAR<=0.001%;FRR<=1% Palm: FAR<=0.01%;FRR<=1%
|
|
Communication |
TCP/IP ( RJ45),USB Host,RS232/485,Wiegand In/Out |
|
Attendance Status |
Check In/Out,Break In/Out,OverTime In/Out |
|
Interfacefor |
3rd party electric lock such as magnetic locks,door sensor,exit/release button,Alarm |
|
Language |
Multi languages ,English,Spanish,French,Portuguese,Arabic,Turkish,Hebrew，etc. |
|
Power Supply |
110/220 VAC-12VDC/3A |
|
Environment |
Operation temperature: 0-45 Celsius, Operation humidity: 20%-80% |
|
Package data |
Machine size:19.4(L)*16.5(W)*86(H)mm Unit packing:31*26*12cm Carton packing:50*34*38CM Real weight:1.65KG Volume Weight 2.1KG |
|
Functions Support |
Scheduled bell, DLST, self-inquiry,Workcode,SMS,T9 input,Webserver,Multi-alarm,Photo ID, User role, Data encryption,ADMS,Multi-verify,Auto state |
|
Optional functions |
ID/MF IC card reader,WIFI,3G/4G, Serial printer, External Siren |
|
Customization |
Can add your boot logo,screensaver logo, can do OEM /Neutral orders |
|
Software |
Web-based attendance cloud server UTime Master or BioTime8.0 |
Web-based Attendance Software:
UTime Master: FA1-PRO is with TA PUSH,ADMS, can connect to icloud server software UTime Master.
Packing List:
